Items

Demand Specifications

Downlink

Uplink

Frequency Range (MHz)

2110~ 2170

1920~ 1980

Max. Output Power (dBm) (Center frequency)

30±2

-10±2

Max. Gain (dB) (Center frequency)

45±3

45±3

ALC (dB)

≤|±2.0|

≤|±2.0|

ALC Range (dB)

0 ~ 20

0 ~ 20

ATT Adjustable Range (dB) ( step 1dB)

0 ~ 25

ATT Adjustable Error (dB)

0-20dB

≤|±1.0|

21-25dB

≤|±1.5|

Ripple in band (dB) (peak to peak)At 25°C

≤5.0

Spurious Emission (dBm)

≤-36dBm/100kHz @ 9kHz~1GHz

≤-30dBm/1MHz @ 1GHz~12.75GHz

3rd IMD (dBc) (Max. Gain)

≤-36(dual-tone interval 600kHz)

PCDE (dB)@WCDMA

≤-35

EVM (%)(rms)

≤12.5%

Time Delay (us)

≤1.5

≤1.5

VSWR（Power Up, Min Gain, Pin=-30dBm）

≤1.8

≤1.8

Noise Figure (dB) (Max. Gain)

/

≤6.0

Items

Specifications

Impedance (Ω)

50

Radio Connector

N(f)

Power Supply

AC100~240V, 50Hz

Weight (Kg)

≤3

Power Consumption (W)

RS232

≤60

RS232+Remote

≤90

Dimension (mm)

RS232

226*174.5*28

RS232+Remote

225*173.5*30

Enclosure Protection Degree

IP30(indoor)

Operating Temperature (℃)

-0 ~ +55

Humidity (%)

95

Control Function

RJ45(RS232), Handle, Remote monitoring is optional
